Cold resistant conveyor belt

Cold resistant rubber conveyor belt

The carcass is made from Polyester fabric, Nylon fabric, Cotton fabric, or Terylene & Cotton fabric, etc. Adopting lower crystal rubber materials as cover rubber, it has not only a strong life period but also
efficient operating even in the low temperature environment. The lowest temperature
can be -50C ( -58F).

There are two grades of Cold Resistant Conveyor Belt :

  1. Depending on the properties of the cover, our cold resistant conveyor belt can be divided into three types, including wear resistant type (H), anti-abrasion type (D), and ordinary type (L).
  2. According to different cold resistance, it can be divided into two types: C1 and C2. C1-working temperature:-45~+50℃; C2-working temperature: -60~ +50℃.

Features :

  • High tensile strength
  • Flame-resistant
  • Static-conductive
  • Resistant to high heat & wear
  • Resistance to the deteriorating effects of materials such as coal treated lightly with oil
  • Capability to perform under extreme temperatures
  • High abrasion resistance
  • Excellent low temperature flexibility
Technical Data :
Grade Min. Tensile Strength (N/mm2) Min. Elongation at Break (%) Max. Abrasion Loss (mm3) Cold resistant coefficient at elongate ≥ Aging test Application Areas:
C1(-45’ C) C2(-60’ C) (-70°C, 168 h) Change rate of tensile strength and breaking elongation (%)
H (Laceration resistant) 24 450% 120 ±25 Ideally suited to applications in the open air of cold environments or freezer stores / warehouses.
D (Anti – Abrasion resistant) 18 400% 100 ±25
L(Ordinary) 15 350% 200 0.3 0.2 ±25
Note: C1: temperature condition is -45°C~+50°C; C2: temperature condition is -60°C~+50°C
