Fire Resistant Conveyor Belt, Belt Thickness: 11 -15 mm
Material : Nylon carcass or EP carcass
Belt Thickness : 11 -15 mm
Operating Temperature Range : 120 to 380 Degree C
Rubber Material Grade : M24
Color : Black
Product Description
The product is made of Nylon carcass or EP carcass and finished through the process of calendaring, assembling, vulcanizing etc, suitable for conveying materials that require a flame resistant and static conductive belts in power, chemical, light, metallurgical and grain processing industries, under the condition of flammable or explosive environment above coal mines.
Cover Type
| Cover Type | Standards | Minimum Tensile Strength (MPA) | Minimum Elongation (%) | Abrasion | Material Covered |
| Fire Resistant | SANS-F | 17 | 350 | 180 | Material with fire hazards, e.g. Coal |
| IS-1891 (FR Grade) |
17 | 350 | 200 | ||
| ISO-340 (FR Grade) |
17 | 350 | 180 | ||
| AS-F (FR Grade) |
14 | 300 | 200 | ||
| AS-1332 (FR Grade) |
14 | 300 | 200 | ||
| DIN S Grade |
17 | 350 | 180 | ||
| DIN K Grade |
17 | 400 | 200 | ||
| MSHA-FR | 17 | 350 | 200 | ||
| CAN/CSA (FR Grade) |
17 | 350 | 200 |
