Specifications
Bucket Elevator Conveyor Belt is the best solution from the technical and cost-efficiency point of view.
Elevator conveyor belt
Advantage:
Suitable for conveying material vertically
High working tensions
Convenient maintenance
High bucket attachment values
Great conveying capacity
Steady running
Belting- PVC- polyester polyvinyl chloride.
Buckets-“Heavy Duty” Polyethylene style CC-HD. (-60 degree F to +225 degrees F)
Bucket Elevator Steel Cord Belt And Jointing Kit are generally secured to belts by means of flat head bolts known as “elevator bolts – No.1 head,” having American standard hex nuts. These bolts are also called “Norway” bolts. No. 2 oval head bolts are used with the heaviest belts and buckets. Leather or polymer washers are sometimes used between the bucket and belt to absorb shock when buckets pass over pulleys. They also serve as spacers to reduce accumulation of material between the bucket and belt, and help seal the boltholes against moisture. One washer is used per bolt. The belt carrying the buckets should be at least 1 inch wider than the bucket for bucket widths up to 16 inches, and 2 inches wider than the bucket for widths 16 inches and over. When two lines of buckets are used on the same belt they should be staggered with respect to each other.
